船用蒸汽发生器给水系统的容错控制

赵淑琴; 张永生

doi:10.3969/j.issn.1673-3185.2016.02.016

船用蒸汽发生器给水系统的容错控制

中国舰船研究设计中心, 湖北武汉 430064

基金项目:

国家部委基金资助项目

详细信息

作者简介:
赵淑琴: 张永生,男,1982年生,博士,工程师。研究方向:动力装置控制与仿真。E-mail:zhang-262519@163.com

通讯作者:
赵淑琴(通信作者),女,1978年生,硕士,工程师。研究方向:动力装置控制与仿真。E-mail:52228799@qq.com

中图分类号: U664.11
计量
- 文章访问数: 348
- HTML全文浏览量: 66
- PDF下载量: 150
出版历程
- 收稿日期: 2015-04-07
- 网络出版日期: 2023-02-10
- 刊出日期: 2016-04-07

Fault tolerant control of the water-feeding system of steam generators

China Ship Development and Design Center, Wuhan 430064, China

船用蒸汽发生器给水系统的容错控制赵淑琴，采用知识共享署名4.0国际许可协议进行许可。

摘要

摘要: 为提高二回路控制系统的可靠性,以蒸汽发生器给水系统为对象,设计基于BP神经网络的水位容错控制系统。利用Matlab/Simulink仿真平台,建立容错控制仿真模型,并与蒸汽发生器的集总参数仿真模型联合,分别对水位传感器恒偏差、恒增益和卡死故障进行仿真测试。仿真结果表明,容错控制系统的故障诊断模块能够准确、迅速地诊断出传感器故障并启动容错控制模块进行容错控制,使得蒸汽发生器的水位能够稳定在设定值附近,系统运行稳定。基于BP神经网络的容错控制系统对于修正蒸汽发生器水位传感器的故障有效,可用于蒸汽发生器给水控制系统的设计,提高系统的可靠性。
- 蒸汽发生器 /
- 给水 /
- 容错控制
Abstract: In order to improve the reliability of the secondary circuit control system, a steam generator is taken in this paper as the research object, and a fault tolerant control system of the water level is accordingly designed based on BP neural network.Fault tolerant control simulation is also conducted on the Matlab/Simulink platform, where the lumped parameter dynamic models of the steam generator are joined, and the calculated water level of the steam generator, with the fault of constant deviation, constant gain, or locked, is simulated respectively on the water level sensor.The experimental results show that the sensor faults could be diagnosed accurately and rapidly with the fault diagnosis model, and the fault tolerant control should be implemented when sensor faults occur.Meanwhile, the water level of the steam generator could be regulated close to the target value, and the system works steadily.In brief, the proposed fault tolerant control system based on BP neural network is effective to correct the water level sensor fault of the steam generator, and the system can be applied into the design of the steam generator water-feeding control system, which significantly improves the system reliability.
- steam generator /
- water-feeding /
- fault tolerant control

HTML全文

参考文献(10)

[1]	张醒研. 系统容错控制的方法研究[D]. 哈尔滨:哈尔滨工程大学,2011.
[2]	王佳. 小型反应堆故障诊断与容错控制方法研究[D]. 哈尔滨:哈尔滨工程大学,2007.
[3]	周东华,叶银忠. 现代故障诊断与容错控制[M]. 北京:清华大学出版社,2000.
[4]	赵雪萍. 基于BP网络的容错控制的研究[D]. 郑州:郑州大学,2005.
[5]	王德军. 故障诊断与容错控制方法研究[D]. 长春:吉林大学,2004.
[6]	LI J Y,XIA H. Application of fuzzy neural network to fault diagnosis of sensor with mechanical properties in nuclear power plant[J]. Advanced Materials Research, 2013,644:68-71.
[7]	邓志红,施小成,夏国清,等. 核电厂蒸汽发生器的容错控制[J]. 核动力工程,2010,31(1):107-111 , 116.DENG Zhihong,SHI Xiaocheng,XIA Guoqing,et al. Fault tolerant control for steam generators in nuclear power plant[J]. Nuclear Power Engineering,2010,31(1):107-111,116.
[8]	张伟,邓志红,夏国清,等. 蒸汽发生器故障诊断和容错控制中强跟踪滤波的应用研究[J]. 核动力工程,2011,32(6):23-27. ZHANG Wei,DENG Zhihong,XIA Guoqing,et al. Research on fault diagnose and fault tolerant control of steam generator based on strong tracking filter[J]. Nuclear Power Engineering,2011,32(6):23-27.
[9]	张永生,马运义,高伟,等. U型管蒸汽发生器的简化集总参数动态模型[J]. 中国舰船研究,2010,5(4):52-55. ZHANG Yongsheng,MA Yunyi,GAO Wei,et al. A simplified lumped parameter dynamic model for U-tube steam generator[J]. Chinese Journal of Ship Research,2010,5(4):52-55.
[10]	张永生,马运义,高伟,等. 核动力蒸汽发生器水位的前馈反馈控制[J]. 船海工程,2010,39(4):132-134. ZHANG Yongsheng,MA Yunyi,GAO Wei,et al. Feedforward-feedback control of water level for the nuclear powered steam generator[J]. Ship and Ocean Engineering,2010,39(4):132-134.
